Cooler Master V Platinum Series 1000W 80Plus Platinum Certified Full Modular Power Supply With 1X 135mm TBB Fan And Single And Multi-Rail Switch - Black Colour
Features:
-Thermal Regulation Mode*
-Build with 1x 135mm TBB Fan**
-Built-in single and multi-rail switch***
-Highly efficient and quiet operation
-Guaranteed typical efficiency of 92%
-80Plus Platinum efficiency certification
-Comes with improved 16AWG PCI-e Cables
-Full modular cabling and 100% Japanese capacitors
-Full-bridge LLC resonant converter and DC-DC technology
Specifications:
-Product Name: V1000 Platinum
-Item Code: MPZ-A001-AFBAPV
-ATX Version: ATX 12V
-PFC: Active PFC
-Input Voltage: 110-240V
-Input Current: 13-87A
-Input Frequency: 50-60Hz
-Fan Size: 135mm
-Fan Bearing: TBB
-Efficiency: 92% @ Typical Load
-80 PLUS Rating: 80 Plus Platinum
-ErP 2014 Lot 3: Yes
-Operating Temperature: 0~50°C
-MTBF: >100,000 hours
-Protections: OCP/OPP/SCP/OCP/UVP/OTP
-Regulatory: cTUVus, TUV, CE, CCC, FCC, EAC, RCM, BSMI, KC
Cable Connectors:
-1x ATX 24 Pin
-1x EPS 4+4 Pin
-1x EPS 8 Pin
-12x SATA
-8x Peripheral 4 Pin
-1x FDD
-8x PCI-e 6+2 Pin
NOTES:
-*Keeps the PSU quiet & stable by maintaining a constant fan speed up to 60% of the maximum load, this increases the lifespan of the PSU by keeping the fan under minimal stress w/o risking the safety or performance of the system as a whole.
-**This special TBB fan bearing can operate safely and reliably in temperatures up to 70°C.
-***Easily use multi-rail mode for normal use & single rail mode for specialized needs such as overclocking, change modes with flick of a switch.
-Weight: 3338g
-Dimensions: (L)41 x (W)37 x (H)23.5cm
What's in the box:
-1x CM V1000 80+ Platinum PSU
