General/Power Consumption | 5 W @ 24 VDC (typical) |
General/Certifications | CE, FCC class A |
General/Weight | 310 g |
General/Dimensions | 60 x 139 x 100 mm |
General/Enclosure Housing | ABS+PC |
System Hardware/CPU | Marvel XScale PXA270 520 MHz |
System Hardware/Memory | 32M bytes, SDRAM 64M bytes |
System Hardware/Storage | 1 x Type II CompactFlash card slot |
System Hardware/USB Ports | 1 x USB 1.1 |
Processor System/Watchdog Timer | Yes |
System Hardware/Battery Backup Memory | 256 KB file system, 256 KB direct access |
System Hardware/Real-time Clock | Yes |
System Hardware/VGA | DB15 connector |
General/OS Support | Windows CE |
Software/Control Software | C/C++ and .NET library KW Multiprog (development tool), KW ProConOS (runtime kernel) |
Environment/Temperature (Operating) | -10 ~ 55°C (when mounted vertically) |
Environment/Temperature (Storage) | -40 ~ 70°C |
I/O Expansion/Connected I/O Modules | 32 (max.)* |
I/O Expansion/Digital Signals | 768 (max.) |
I/O Expansion/Analog Signals | 192 (max.) |
Communications (Ethernet)/LAN | 2 x RJ-45 Port, 10/100 Mbps |
Communications (Serial)/Medium | 2 x Isolated RS-485 (2-wire, isolated) |
Communications (CAN)/Medium | 2 x Isolated CAN |
Communications (CAN)/Speed | Maximum 1 Mbps |
General/Dimensions (W x H x D) | 60 x 139 x 100 mm |
General/Enclosure | ABS+PC |
System Hardware/Memory Flash | 32 MB, SDRAM 64MB |
System Hardware/Watchdog Timer | Yes |
Software/OS Support | Windows CE |
Environment/Relative Humidity | 5 ~ 95% (non-condensing) |
