D-LINK - LA-DL-GS1016D



D-LINK 16PORT GIGABIT SWITCH UNMANAGED

Description

D-LINK GS1016D, 16Port Gigabit Switch Unmanaged, offers an economical way for SOHO and small to medium businesses (SMB) to benefit from the increased bandwidth of Gigabit Ethernet.


Specification

D-Link 16Port Gigabit Unmanaged Switch

Key Features:
D-Link Green Technology
Power saving by cable length detection and link status
Inexpensive Gigabit solution for SOHO/SMB
Silent, fanless design
Auto MDI/MDI-X crossover for all ports
Store-and-forward switching scheme
Full/half-duplex for Ethernet/Fast
Ethernet speeds
IEEE 802.3x Flow Control
Supports 9,600Bytes Jumbo Frames
Supports IEEE 802.1p QoS (4 Queues, Strict Mode)
Supports Cable Diagnostics Function
Supports D-Link’s unique EEE+ mode
RoHS compliant
Plug-and-play installation

Number of Ports: 16 Gigabit ports
Switching Fabric: 32 Gbps switching fabric

Standards:
IEEE 802.3 10BASE-T Ethernet (twistedpair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper)
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.1p QoS (4 queues, strict mode)
IEEE802.3az EEE

Protocol: CSMA/CD
Data Transfer Rates:
Ethernet:
10 Mbps (half duplex)
20 Mbps (full duplex)
Fast Ethernet:
100 Mbps (half duplex)
200 Mbps (full duplex)
Gigabit Ethernet: 2000 Mbps (full duplex)

Topology: Star
Network Cables
10BASE-T:
UTP CAT 3, 4, 5/5e (100 m max.)
EIA/TIA-586 100-ohm STP (100 m max.)
100BASE-TX, 1000BASE-T:
UTP CAT 5/5e (100 m max.)
EIA/TIA-568 100-ohm STP (100 m max.)

Media Interface Exchange: Auto MDI/MDI-X adjustment for all ports
LED Indicators:
Per port: Link/Activity/Speed
Per device: Power

Transmission Method: Store-and-forward
MAC Address Table: 8K entries per device
MAC Address Learning: Automatic update
Packet Filtering/Forwarding Rates (half duplex):
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port
Gigabit Ethernet: 1,488,000 pps per port

RAM Buffer: 512 KB per device
Power Consumption:
Standby: 3.8 watts
Maximum: 11.0 watts

Heat Dissipation:
Standby: 12.958 BTU/h
Maximum: 37.51 BTU/h

Acoustics: 0 dB
MTBF: 1,087,450 hours

Operating Temperature: 0 ° to 40 °C (32 ° to 104 °F)
Storage Temperature: -10 ° to 70 °C (14 ° to 158 °F)
Storage Humidity: 5% to 90% RH non-condensing
Dimensions: 280 x 180 x 44 mm (11.02 x 7.09 x 1.73 inches)
Weight: 1.59 kg (3.51 lbs)

Certifications:
FCC Class A
ICES-003 Class A
CE Class A
C-Tick Class A
VCCI Class A
cUL
CB
