Specification
WESTERN DIGITAL TV MINI MEDIA PLAYER
Specification:
Kits Contents:
Media player
Compact remote with batteries
Composite AV cable
Component AV cable
AC Adapter
Quick Install Guide
Compatibility:
AAC, MP3, JPEG, USB 2.0, Energy Star, Real Media
Note: Compatibility may vary, depending on user's hardware configuration and operating system.
Media File Format Support (Based on Firmware Version 1.00.60):
Movie:
AVI (Xvid, MPEG1/2/4), MPG/MPEG, VOB, MP4/MOV (MPEG4), RM or RMVB 8/9/10
RMVB supports up to 1024x576x24 or 800x600x30 compressed video resolution
MPEG1/2/4 supports up to D1 resolution (720x480 in NTSC, 720x576 in PAL)
MPEG2 ML/MP conforming to ISO-13818
MPEG1 ML/MP conforming to ISO-11172
Subtitle: SRT, SSA, SUB, SMI
Picture: JPEG, GIF, TIFF, BMP, PNG
Audio:
MP3, WAV/PCM/LPCM, WMA, AAC, FLAC, MKA, OGG, Real Audio, APE
An audio receiver is required for multi-channel surround sound digital output.
Interfaces:
USB 2.0 (input)
Component A/V (output)
Composite A/V (output)
Physical Dimensions:
Height: 0.8 in (21 mm)
Length: 3.6 in (91 mm)
Width: 3.6 in (91 mm)
Weight: 3.98 oz (113 gm)
Power Requirements:
AC Input Voltage: 100~240 VAC
AC Input Frequency: 50~60 Hz
Environmental Specifications:
Operating Temperature: 41°F (5°C) to 95°F (35°C)
Non-Operating Temperature: -40°F (-40°C) to 149°F (65°C)
