Specification
MSI B85M-E45 Motherboard
Supports 4th Gen Intel Core / Pentium / Celeron processors for LGA 1150 socket
Supports DDR3-1600 Memory
USB 3.0 + SATA 6Gbps
Military Class 4: Top Quality & Stability
Military Class Essentials: Total Protection for Military Class Motherboards
OC Genie 4: Overclock in 1 Second
Click BIOS 4: Easily Fine-tune Your System
4K UHD Support: Ultra-high Definition Visual Experience
3 Display Outputs: HDMI/DVI/D-Sub Support
PCI Express Gen 3: World's 1st PCI Express Gen 3 Motherboard Brand
Command Center: Control & Customize Your PC Settings
Fast Boot: Quickly Boot Up & Enter OS in A Few Seconds
M-Flash: Simply Update & Backup Your BIOS
Live Update 5: Easily Update The Latest BIOS & Drivers
Intel Small Business Advantage 2.0: Streamline PC maintenance & Security
Specification:
CPU: Supports 4th Generation Intel Core i7/5/3/ Pentium/Celeron processors for LGA 1150 socket
Chipset: Intel B85 Express Chipset
Main Memory:
Supports four unbuffered DIMM of 1.5 Volt DDR3 1066/1333/1600 DRAM up to 32GB Max
Supports Dual channel mode
Supports non-ECC, un-buffered memory
Supports Intel Extreme Memory Profile (XMP)
Slots:
1x PCIe 3.0 x16 slot
2x PCIe 2.0 x1 slots
1x PCI slot
On-Board SATA:
SATAIII:
Up to 6Gbps transfer speed
Supports four SATAIII port (SATA1¬4) by B85
SATAII:
Up to 3Gbps transfer speed
Supports two SATAII ports (SATA5¬6) by B85
USB:
4x USB 3.0 ports
8x USB 2.0 ports
Audio:
Realtek ALC887
7.1-Channel High Definition Audio
LAN: Supports one PCI Express LAN 10/100/1000 Fast Ethernet by Realtek 8111G
Internal I/O Connectors:
1x ATX 24-Pin power connector
1x 4-pin ATX 12V power connector
1x 4-pin CPU fan connector
1x 4-pin system fan connector
1x 3-pin system fan connector
4x SATA 6Gbps connectors
2x SATA 3Gbps connectors
1x Clear CMOS jumper
2x USB 2.0 connectors
1x USB 3.0 connectors
1x Serial port connector
1x Parallel port connector
1x TPM Module connector
1x Front Panel Audio connector
1x Chassis Intrusion connector
Back Panel I/O Ports:
1x PS/2 Keyboard port
1x PS/2 mouse port
4x USB 2.0 ports
2x USB 3.0 ports
1x RJ45 LAN jack
1x HDMI port, supporting the maximum resolution of 4096x2160@24Hz
1x DVI-D port, supporting a maximum resolution of 1920x1200@60Hz
1x Graphics port, supporting a maximum resolution of 1920x1200@60Hz
Dimension: 9.0" x 9.6" (22.8 cm x 24.4 cm) Micro-ATX Form Factor
Mounting: 6 mounting holes
