Specification
INTEL NUC DN2820FYKH
Specifications:
Essentials:
Product Collection: Legacy Intel NUC Kits
Code Name: Products formerly Forest Canyon
Board Form Factor: UCFF (4" x 4")
Socket: Soldered-down BGA
Internal Drive Form Factor: 2.5" Drive
# of Internal Drives Supported: 1
Lithography: 22 nm
TDP: 7.5 W
DC Input Voltage Supported: 12 VDC
Processor Included: Intel Celeron Processor N2830 (1M Cache, up to 2.41GHz)
Memory & Storage:
Max Memory Size(dependent on memory type): 8GB
Memory Types: DDR3L-1066/1333 1.35V SO-DIMM
Max # of Memory Channels: 1
Max Memory Bandwidth: 10.7 GB/s
Max # of DIMMs: 1
Processor Graphics:
Integrated Graphics: Yes
# of Displays Supported: 1
Expansion Options:
PCI Express Revision: Gen2
PCI Express Configurations: Half-length MiniPCI card with PCIe x1 lane
PCIe Mini Card Slot (Half Length): 1
I/O Specifications:
# of USB Ports: 3
USB Configuration: 1x front and 2x rear USB 2.0
USB Revision: 2.0, 3.0
USB 2.0 Configuration (External + Internal): 2 + 0
USB 3.0 Configuration (External + Internal): 1 + 0
Total # of SATA Ports: 1
Max # of SATA 6.0 Gb/s Ports: 1
Audio (black channel + front channel): 7.1 digital + analog stereo headset
Integrated LAN: 10/100/1000
Integrated Wireless: Intel Wireless-N 7260 + Bluetooth 4.0
Integrated Bluetooth: Yes
Consumer Infrared Rx Sensor: Yes
Advanced Technologies:
Intel HD Audio Technology: Yes
Intel Virtualization Technology (VT-x): Yes
